| MOQ: | 1 |
| 価格: | 2500 |
| Parameter | Specification |
|---|---|
| Pressure capacity | 30 Ton |
| Pressure gauge | Dual node pressure adjustable, pressure adjustment accuracy of 10% |
| Platen size (mm metric) | 250*250/300*300/350*350/400*400/450*450/500*500/600*600mm (optional) |
| Hot platen material | High temperature resistant imported steel plate, surface carbide quenching, special treatment for fast heat conduction, pressure parallel non-deformation, wear-resistant |
| Platen hardness | 50~60HRC |
| Platen Flatness | ≤0.03mm |
| Platen flatness and parallelism | ≤0.16mm |
| Temperature range | Normal temperature -250ºC (customizable up to 500ºC) |
| Temperature uniformity | 2.5ºC (uniformity decreases with larger platen size and higher temperature) |
| Temperature controller | Precision module with PLC touch screen control, display inside the touch screen, numerical value display |
| Temperature control method | Temperature control motherboard precision control, self-tuning with high-precision sensors, temperature display accuracy: ± 1.0 ºC |
| Timer | Setting display in touch panel, time range 0.1S~99min~9.9hr |
| Heater | Heating mold built-in cylindrical (power varies according to platen area configuration) |
| Rising time | Normal temperature~160ºC about 15mins |
| Two hot plates | The hot plate can be set to control the temperature separately |
| Heating method | Electrical heating |
| Cooling method | Water cooling |
| Hydraulic system | CREE.6 hydraulic flow closed-loop control system, oil pump drive high-performance electro-hydraulic with high-precision non-resistance cylinder piston execution rate control mode, with pressure automatic compensation function |
| Cylinder Stroke | Max 150mm (customizable) |
| Cylinder speed | 11mm/s |
| Pressure gauge | 0~200kg/sq.cm |
| Mold opening method | Fully automatic rise and fall (with manual-automatic dual function) |
| Safety device | Safety guards, safety doors |
| Number of safety devices | Four |
| Main unit volume | (W×D×H)1200×750×1650 mm |
| Power Voltage | 3∮,AC380V |
| Weight | ≈680kg |
